SIAMESE SAMPLING TRAWL
Siamese trawl, Mini-Missouri trawl
Hands down.... the Siamese Trawl is the most popular, efficient benthic sampling gear for Year 01 specimens that we build or that we have ever seen ! It is the most sought after trawl in the benthic, inland sampling venue. Accept NO substitues or "Knock-Off" nets. We spent years perfecting this design and IT WORKS!




What makes the Siamese Trawl so efficient?
1. The ST-8 comes in a nice, compact, 8' Head Rope size
2. It is built with 1000 denier x Tire Cord Polyester   material  * Not the cheaper Nylon Delta, Heavy Delta, etc.  used by competitors. *
3. The Otter Doors are heavy duty, 24 x12 marine plywood with 1/2" steel runners , bracing and Steel Tie Pads on the rear. The doors are bolted, not nailed. The chains are held in place with Steel chocks, not staples.
4. The mesh is 4mm Raschel mesh with a 3 strand Crossover for added strength.
5. The  Leading edges of the Cork line and Lead line are reinforced with  Dyneema netting and doubled stitched
6. 3/8" Polydacron lines
7. No 24 Spun nylon Gripps
8. 12 oz. floats
9. 3/16" Bolshline chain Lead Line for superior bottom contact
10. 38mm str. Separator Bag installed in the Cod End to catch larger specimens first
11. 4mm x 1000 denier Secondary Bag to catch and retain smaller specimens down to 3-5mm
12. 36" Trash Zipper installed on top of the trawl at the Cod End to remove large debris . . .  its a life saver on boulders, logs, old tires and such.
13. Everything treated in a Latex net coat solution.

The Siamese is our most popular seller and has been used by researchers the world over . . . both fresh and salt water environs.




Siamese Sampling trawl
In 2002, I.N.S. designed the  first Siamese Trawl. Shown here is  the very first Model.
Joe Gerken, a Fishery student at Kansas State, tested this model side by side with the H.A.T. Mini-Missouri Trawl  for two years.The Siamese out performed the Mini Missouri by a long shot.

I.N.S.  never looked back . . . .  The Siamese does EVERYTHING the Mini does only faster, easier and less expensive.

By 2025, we dont even get asked for Mini- Missouri trawls any longer. Its all Siamese trawls.

These simple yet efficient sampling trawls have made their way around the world . . . Borneo, Africa, Australia, New Zealand, Canada, The deep Amazon forrest and river system, Pacific ocean environs, and many , many other locations.

They can be configured with numerous design additions to work in almost any environ. They are the best Benthic Sampler we have for Year 01  specimens.

Joe Gerken with a freak catch of a 40lb. Flat head, in the Siamese Trawl.
These nets are NOT meant to take this big of a catch . . . THIS must have been a really dumb fish!

The Siamese  regularly takes fishes from 5mm through 50mm in Longitudinal Axis lengths.

The Siamese trawl is faster, lighter and easier spreading than the Mini-Missouri.  It separates large and small fishes inside the codend, where they are more easily collected. It reduces the crushing effect that the Mini Missouri trawl has. It has been tested side by with the Mini and it came up equal to or surpassing the older dual mesh net every time.

I.N.S. makes this offer;
IF you buy a Siamese trawl and do not like it after two weeks, send it back and we will make you a Mini-Missouri for the difference in costing and the shipping.* the net has to be in good condition....no holes or rips.

This is a true scale of what the Siamese takes. The first 4 of these fish were held in the LARGE MESH Cod End. The rest filtered through and were retained in the 12mm, SMALLER MESH COD END. . . . .  simple, fast, excellent physical condition of catch and  highly efficient!
